SSH Steel Structure Hangar buildingMore >
Lifting capacity(t):5 , 10
Span(m):10.5-31.5 , 10.5-31.5
Lifting height(m):16 , 16
Trolley moving speed(m/min):37.2 , 43.8
Trolley lifting speed(m/min):12.5 , 8.5
Crane running speed(m/min):15.5 , 13.3 , 89.8 , 92.3 , 89.8 , 91.9 , 84.7 , 116.2 , 117.4 , 115.6 , 116.8 , 112.5
Power source:A.C380V 50HZ 3-Phase
Prefabricate Steel Structure Office BuildingMore >
Base materials:Cement and steel foundation bolts
Main frame:H beam (welded or hot rolled)
Purlin:C purlin (C120-320) or Z Purlin (Z100-200)
Bracing:Tie bar, lateral bracing, column bracing, knee bracing, etc
Bolt:Normal bolt, high strength bolts, Galvanized bolt
Roof & wall:Sandwich panel, steel corrugated sheet
Door:Sliding door , rolling shutter
Window:PVC window, aluminum-alloy Window
Accessories:Skylight, ventilation, downpipe and galvanized gutter etc .
steel structure office buildingMore >
Item Name:Steel structure building
Size:Length, Width, Roof height and Eave Height
Roof and Wall:PU, EPS, Rock Wool sandwich panel
Door and Window:PVC or Aluminum Alloy
Column and Beam:Hot rolled H section , I section or Galvanized
Purlin:C-Section and Z-section
Surface:2 primer and 1 finished paint
Local Climate:1. wind speed 2. Rain load 3. Snow load 4. Earthquake grade if any, etc.
Crane parameter:If need crane beam, parameter is in need.
Drawing:1. Quote as clients' drawing 2. Design as per clients' requests.
Package:In container or as per requests.
Load in:20 ft', 40 ft' GP, /HQ/OT container
Double Door Steel Structure Garage BuildingMore >
Main structure:Steel Welded H Section
Purlin:C Section Channel or Z Section Channel
Roof Cladding:Sandwich Panel or Corrugated Steel Sheet with Fiber Glass Wool Coil
Wall Cladding:Sandwich Panel or Corrugated Steel Sheet
Tie Rod:Circular Steel Tube
Column & Transverse Brace:Angle Steel or H Section Steel or Steel Pipe
Knee Brace:Angle Steel
Roof Gutter:Color Steel Sheet
Door:Sliding Sandwich Panel Door or Metal Door
Windows:PVC/Plastic Steel/Aluminum Alloy Window
Connecting:High Strength Bolts
Packing:Can be loaded into 40ft'GP/HQ/OT, or 20 ft'container.
Drawing:We can make the design and quotation according to your requirement or your drawing
