• Steel Structure Warehouse in Libya Steel Structure Warehouse in Libya

Steel Structure Warehouse in Libya

  • Place of origin : Guangdong,China
  • Model Number : Steel structure warehouse06
  • Price Terms : FOB price
  • Payment Terms : By T/T
  • Package : Seaworthy
  • Minimum Order : 1 set
  • Delivery Time : 30-45 days
  • Brand Name : SBS

Steel Structure Warehouse in Libya

1、STEEL STRUCTURE WORKSHOP

Steel Structure Warehouse is mainly refers to the main bearing component is composed of steel. Including the steel columns, steel beam, steel structure, steel roof truss (of course the span of plant is bigger, basic is the prefabricated steel structure truss now), steel roof, pay attention to the wall of the steel structure maintenance also can use brick wall.Foshan Shengbang Steel Structure Co., Ltd. is one of the reliable steel structure manufacturers and suppliers in China, and our factory can offer you cheap and low price steel structure, warehouse, workshop, prefab house, container house,etc.

2.steel structure material


  The steel structure material is included the H section,I section,Square tube,Circular Tube,Floor decking steel sheet,C section,Z section,Angle iron,Steelbar,Steel plate.

Steel Structure Warehouse formed by Steel Column , Steel Beam ,Bracing ,Purlin , all the Steel Structure Fabricated in Workshop and delivery to Project site , quickly installation , green building and save manpower .
Steel Structure Warehouse is formed by the main framework through linking up the H beam,C purline,Z purline,U purline steel components.
Roof and wall using a variety of panels together with other components such as windows and doors.



C section steel section size                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Z section steel section size

model

Size(mm)

Hole size(mm)

h

H

B

B

G

T

C80

80

40

40

15

2.0-3.0

No punched hole

 note

C100

100

50

50

20

2.0-3.0

40





We can custom by clients requirements.

C120

120

50

50

20

2.0-3.0

Pitch adjustable

C140

140

50

50

20

2.0-3.0

Pitch adjustable

C150

150

60

60

20

2.0-3.0

Pitch adjustable

C160

160

60

60

20

2.0-3.0

Pitch adjustable

C180

180

60

60

20

2.0-3.0

Pitch adjustable

C200

200

60

60

20

2.0-3.0

Pitch adjustable

C250

250

70

70

20

2.0-3.0

Pitch adjusta




model

Size(mm)

Hole size(mm)

h

H

B

b

G

t

Z100

100

55

50

20

2.0-3.0

40

 note

Z120

120

55

50

20

2.0-3.0

Pitch adjustable





We can custom by clients requirements.

 Z140

140

55

50

20

2.0-3.0

Pitch adjustable

Z150

150

67

61

18

2.0-3.0

Pitch adjustable

Z160

160

67

61

20

2.0-3.0

Pitch adjustable

Z180

180

67

61

20

2.0-3.0

Pitch adjustable

Z200

200

67

61

20

2.0-3.0

Pitch adjustable

Z250

250

78

72

20

2.0-3.0

Pitch adjustable

Z280

280

78

72

20

2.0-3.0

Pitch adjustable

Z300

300

78

72

20

2.0-3.0

Pitch adjustable










































Steel-Structure-Warehouse-in-Libya-2.jpgSteel-Structure-Warehouse-in-Libya-3.jpgSteel-Structure-Warehouse-in-Libya-4.jpgSteel-Structure-Warehouse-in-Libya-5.jpg



3、Product detials

1.Opinions

1)We can supply all kinds of steel structures, steel building, metal building, modular house, steel frame for warehouse, workshop, garage etc, steel beams, other riveting and welding parts.

2)We can also make and develop new parts according to customers' drawings and detailed dimensions.

2. Specifications

1) Size: MOQ is 200m2, width X length X eave height, roof slope

2) Type: Single slope, double slope, muti slope; Single span, double-span, Multi-span, single floor, double floors

3) Base: Cement and steel foundation bolts

4) Column and beam: Material Q345(S355JR)or Q235(S235JR) steel, all bolts connection! Straight cross-section or Variable cross-section

5) Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc

6) C or z purlin: Size from C120~C320, Z100~Z200

7) Roof and wall panel: Single colorful corrugated steel sheet 0.326~0.8 mm thick, (1150 mm wide), or sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50 mm ~ 100 mm.

8) Accessories: Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, etc

9) Surface: Two lays of Anti-rust Painting

10) Packing: Main steel frame without packing load in 40'OT, roof and wall panel load in 40'HQ

 3. Design    Parameters

If you need we design for you, pls supply us the following parameter together with detail size

1) Live load on roof (KN/M2)

2) Wind speed(KM/H)

3) Snow load (KG/M2)

4) Earthquake load if have

5) Demands for doors and windows

6) Crane  (if have) , Crane span, crane lift height, max lift capacity, max wheel pressure and min wheel pressure!











































































4、Service flow path:

 Discussing Project——Design Plan Drawing——Budget & Quote——Confirm Drawing&Quotation——Sign the Contract——Make the shop Drawing——Manufacturing——Transportation——Shipping——Foundation Ready——Guidance Installation——Finshed Installation
